The PV Tech 1200 is a compact and efficient solar inverter designed for small-scale residential and backup power applications. It provides a rated output capacity of 1.2 kW with a 2.4 kVA surge capability, ensuring smooth startup of connected appliances. With pure sine wave output and a fast 10 ms transfer time, it delivers stable and reliable performance for sensitive electronic devices. The inverter supports a wide input voltage range and features automatic 50/60 Hz frequency adaptation for flexible installation.

Equipped with a built-in MPPT solar charger, the unit supports up to 1000W PV input with a 12A charging current and an 18–100 VDC MPPT tracking range, maximizing solar energy utilization even in varying sunlight conditions.

The inverter operates on a 12V battery system and is compatible with both lithium-ion and lead-acid batteries. It offers precise battery management with a 13.8V float charging setting and 15V overcharge protection to enhance battery safety and lifespan.

For monitoring and communication, the PV Tech 1200 includes an LCD display interface along with RS232 and RS485 communication ports. It also supports both AC and PV activation modes for flexible operation. Built with IP21 protection, the inverter is designed to operate reliably in temperatures ranging from –10°C to 50°C and at altitudes up to 4000 meters (with derating). Its compact dimensions of 347 × 236 × 91 mm and lightweight 3.2 kg design make it an ideal solution for space-saving solar installations.
